路面冷再生機“液壓系統”的更換要注意什么？
來源：http://www.lzqdw.com/ 日期：2021-07-26
一、液壓系統共由五部分組成：
1、 The hydraulic system consists of five parts:
①分動箱
① Transfer case
②行走泵、行走馬達
② Traveling pump, traveling motor
③工作泵、工作馬達
③ Working pump, working motor
④轉子馬達及減速機
④ Rotor motor and reducer
⑤液壓鋼管及高壓膠管
⑤ Hydraulic steel pipe and high pressure rubber pipe
二、更換條件及標準：
2、 Replacement conditions and standards:
冷再生機在施工過程中負荷較大、液壓系統溫度較高，為使泵和馬達等液壓元件系統中的液壓油黏度處于最佳范圍，建議用戶使用HV46#及以上低溫冷凝抗磨液壓油。
During the construction of the cold regenerator, the load is large and the temperature of the hydraulic system is high. In order to make the hydraulic oil viscosity in the hydraulic component system such as pump and motor in the best range, it is recommended that the user use hv46# and above low-temperature condensation anti-wear hydraulic oil.
根據工程機械設備對液壓系統的要求，初次對液壓系統和濾芯的保養為500小時，考慮油質及費用問題，初次保養方案是將油品進行過濾，只更換濾芯；從第二次保養開始為1000h，因工作強度的大小不一樣，可以根據油脂情況適當延長保養時間。
According to the requirements of construction machinery and equipment for the hydraulic system, the initial maintenance of the hydraulic system and filter element is 500 hours. Considering the oil quality and cost, the initial maintenance scheme is to filter the oil and only replace the filter element; 1000h from the second maintenance. Due to different working intensity, the maintenance time can be appropriately extended according to the oil condition.
若設備運轉使用不足1000小時，因工作強度一般可不更換全部液壓油，但需要放出樣品，看顏色是否清亮，手感粘度是否可以，可采用過濾全部液壓油后更換全部濾芯的方式進行保養。
If the equipment is operated and used for less than 1000 hours, due to the working intensity, it is generally not necessary to replace all the hydraulic oil, but it is necessary to release the sample to see whether the color is clear and whether the hand feel viscosity is OK. The maintenance can be carried out by replacing all the filter elements after filtering all the hydraulic oil.
三、保養方案：
3、 Maintenance scheme:
①更換時機：設備運轉結束后適當?shù)臏囟认拢?0攝氏度以下）更換為最佳時機。
① Replacement time: the best time to replace the equipment at an appropriate temperature (below 50 ℃) after the operation of the equipment.
②更換液壓油及濾芯應具備的場地條件及器具。場地條件：平整清潔的地面（水泥地面最好）。器具：三相電源、200L的油桶三個、濾油機一臺（更換濾芯）、充足的液壓油（HV46#）、濾芯一套、濾芯扳手1件。
② Site conditions and instruments for replacing hydraulic oil and filter element. Site conditions: flat and clean ground (cement ground is the best). Appliances: three-phase power supply, three 200L oil drums, one oil filter (replace filter element), sufficient hydraulic oil (hv46#), one set of filter element and one filter element wrench.
③更換步驟：先將設備的液壓油抽出。拆下全部液壓油濾芯。將事先需要更換的鋼管、膠管安裝好。將新液壓油通過濾油機注入。觀察新的油位是否達到標準油位，直到達標為準。啟動設備后，小負荷運轉設備，使液壓油均勻充滿各部位液壓件。
③ Replacement steps: first draw out the hydraulic oil of the equipment. Remove all hydraulic oil filter elements. Install the steel pipe and rubber hose that need to be replaced in advance. Inject new hydraulic oil through the oil filter. Observe whether the new oil level reaches the standard oil level until it reaches the standard. After starting the equipment, operate the equipment with a small load to make the hydraulic oil fill all parts of the hydraulic parts evenly.
